The HLS-160E20 electric scissor lift for aerial work features a large platform and heavy-duty design. Powered by a quiet and environmentally friendly large-capacity battery, it boasts a width of 2.0 metres and an extended deck capable of carrying the same weight. Equipped with all-terrain, non-marking tyres, it is highly suitable for both indoor and outdoor use. Offering excellent value for money, the HLS-160E20 is a cost-effective electric scissor lift that provides safe and efficient access to elevated workspaces.
Controlbox with quick disconnect
Hourmeter
Charger (high frequency)
230V supply on platform
Driving at full height
Driving, proportional
Lifting, proportional
Differential lock
Descent safety
Flashing beacons
Drive alarm
Emergency descent
Indoors
Outdoors
Certified min. temperature -15ºC
| HLS-160E20 | |
| Max. working height : | 16.00 m |
| Max. platform height : | 14.00 m |
| Min. platform height : | 2.10 m |
| Platform dimensions (retracted) : | 4.00×1.85 m |
| Platform dimensions (extended) : | 6.00×1.85 m |
| Transport height : | 3.26 m |
| Transport height (handrail removed) : | 2.45 m |
| Transport height (handrail folded down) : | 2.49 m |
| Transport dimensions : | 4.50×2.0 m |
| Wheel base : | 3.05 m |
| Ground clearance : | 244 mm |
| Turning radius outside : | 4.00 m |
| Turning radius inside : | 0.00m |
| Max. capacity main platform : | 750 kg (4 pers.+430 kg) |
| Max. capacity roll-out deck : | 750 kg (4 pers.+430 kg) |
| Lift-/lower time (max. load) : | 52/43 sec. |
| Drivig speed (high) : | 3.6 km/h |
| Drivig speed (slow) : | 0.4 km/h |
| Tyres : | 33×12-20 |
| Gradeability : | 25% |
| Batteries (traction acid) | 420 Ah/k5/48 V |
| Gross weight : | 7860 kg |
HLS-160E20
